Industrial Grade PCD Circular Saw Blades Cutting Wood Aluminum Diamond Saw Blade
Detail Information
| Product Name: | Diamond saw blade | Model: | PCD saw blade cutter |
|---|---|---|---|
| Material: | PCD Japan /GE | Workpiece: | Aluminum,Brass, Ceramic, Acrylic, MDF, wood |
| Usage: | Cutting | Type: | PCD/Brazing |
| Size: | 100mm-1500mm | Feature: | High Wear-resistance /Few BUE/Long Life |
| Application: | Cutting machine, | Package: | 1pcs/Box |
| Highlight: |
Diamond saw blade,High finish PCD saw blade cutter for aluminum, Brass,FRP, Plastic, MDF,Acrylic. etc,,Long Life and Burrs free Saw blade; |
||
Product Description
High Quality Industrial Grade PCD Circular Saw Blades Cutting Wood Aluminum Diamond Saw Blade
Features:
- Diamond Saw Blade for Aluminum, aluminum alloys, Ceramic, stone slabs, marble, Fiberglass, PVC pipes, wood .etc use ;
- Free of Burrs; No chipping and breaking;
- Imported high-quality Diamond/PCD raw materials from Japan & USA/GE;
- High precision at 0.1mm and hardness;
- High quality coating material from Germany;
- Durable and Highly wear-resistant;
- High processing efficiency;
- Stable performance;
- Good impact resistance;
- 1.To be used for processing of Aluminum, aluminum alloys, Fiberglass, PVC pipes,Wood,Acrylic, etc ;
- 2.Bring good surface roughness after processing;
- 3.With highly wear-resistant Diamond PCD brazed & plating coating or other quality coating, can be used for high-speed and high finish processing;
- 4.High toughness, using grain-sized Diamond as the raw material;
- 5.Help to increase the smoothness, reduce the friction coefficient,and improve the working efficiency, thus save more production time;
Important Notes:
-
- To be made according to your special demands ;
- 100% Quality Warranty ;
- 100% Inspection under Famous equipments;
- Fast Delivery in 5-7 days;
- Over 30 years experience in precision cutting tools;
- With 30 years experience technician and R&D center in Japan;
- With Branches in Singapore / Japan / China / USA / Mexico / Brazil / UK / Philippines / Malaysia / Turkey/ Argentina;
- Product positioning: High Quality + Reasonable Price.
- Shipping By Fedex /DHL /UPS;
Note:
- If the following Diamond saw blade cutter cannot meet your requirements, we support OEM customized production. The Bit diameter of 100mm to 1500mm, and logo can be customized, including inch size drill. Please contact us to select or customize non-standard diamond according to your needs.
| Tipped Saw Blade- Specific use only | |||
| Fully sintered diamond saw blade | For PVC/ Fiber glass | For granite | PCD tipped saw for Wood |
| 全烧结PCD锯片Ø76mm×Ø12.7mm×0.23mm | 150x20x1.5mm (PVC） | 320*50孔 长(21)齿款 | PCD300*3.2厚*30孔*60齿 |
| 全烧结PCD锯片Ø100mm×Ø12.7mm×0.33mm | 200×25.4×2.5mm (PVC） | 350*50孔含齿370峰利款 | PCD300*3.2厚*30孔*72齿 |
| 全烧结PCD锯片Ø76mm×Ø12.7mm×0.2mm | 250×25.4×2.5mm (PVC） | 350granite 20高齿锋利款380A款 | PCD300*3.2厚*30孔*80齿 |
| 全烧结PCD锯片Ø100mm×Ø12.7mm×0.35mm | 250x30x2.5mm (PVC） | 400granite 20高齿锋利款430A款 | PCD300*3.2厚*30孔*96齿 |
| 全烧结PCD锯片Ø150mm×Ø12.7mm×0.60mm | 300×25.4×2.8mm (PVC） | 450 granite 长(32)齿款 | PCD350*3.5厚*30孔*84齿 |
| 边缘烧结PCD锯片Ø150mm×Ø12.7mm×0.6mm | 300x30x2.8mm (PVC） | 500 granite 长(36)齿款 | PCD350*3.5厚*60孔*84齿 |
| 边缘烧结PCD锯片Ø180mm×Ø16mm×0.7mm | 350x30x2.8mm (PVC） | 600 granite 长(42)齿款 | PCD350*4.4厚*30孔*84齿 |
| 边缘烧结PCD锯片Ø200mm×Ø25.4mm×1mm | 400x30x3.2mm (PVC） | 1200*100D granite | PCD350*4.4厚*60孔*84齿 |
| 边缘烧结PCD锯片Ø200mm×Ø25.4mm×1.2mm | 450x32x3.2mm (PVC） | PCD350*4.4厚*75孔*84齿 | |
| 边缘烧结PCD锯片Ø127mm×Ø12.7mm×0.4mm | 500x50x3.6mm (PVC） | PCD380外径*4.4厚*30/60孔*84齿 | |
| 边缘烧结PCD锯片Ø100mm×Ø12.7mm×0.4mm（无开叉） | 250×25.4×2.5mm (Fiberglass） | PCD380*4.4厚*75孔*84齿 | |
| 边缘烧结PCD锯片Ø200mm×Ø32mm×1.2mm | 300×25.4×2.8mm (Fiberglass） | PCD400外径*4.4厚*60孔*84齿 | |
| 边缘烧结PCD锯片Ø250mm×Ø32mm×1.5mm | 300x30x2.8mm (Fiberglass） | PCD400*4.4厚*75孔*84齿 | |
| 微齿PCD锯片Ø100mm×Ø12.7mm×0.3mm | 300x32x2.8mm (Fiberglass） | PCD450*4.8厚*75孔*84齿 | |
| 微齿PCD锯片Ø150mm×Ø12.7mm×0.6mm | 350×25.4×2.8mm (Fiberglass） | ||
| 电镀PCD锯片Ø100mm×Ø12.7mm×0.5mm | 350x30x2.8mm (Fiberglass） | ||
| 350x32x2.8mm (Fiberglass） | |||
| 400x30x3.2mm (Fiberglass） | |||
| 400x32x3.2mm (Fiberglass） | |||
| 450x32x3.2mm (Fiberglass） | |||
| 500x50x5mm (Fiberglass） | |||
| 600x50x5mm (Fiberglass） | |||
| 700x50x7mm (Fiberglass） | |||
| 800x50x3.2mm (Fiberglass） | |||
Instructions:
1. Before using the diamond saw blade, please measure the tool deflection. If the tool deflection accuracy exceeds 0.1mm, please correct it before cutting.
2. The shorter the shank extends out of the collet, the better. If the tool extends out longer, reduce the speed, feed speed or cutting amount.
3. In case of abnormal vibration or sound during cutting, please reduce the speed and cutting amount until the situation is improved.
4. Spray type and air jet type are preferred for steel cooling, which can improve the use effect of tools.
5. Note: Suitable for low speed machines such as rotary table and electric hand use.
Applications:
Aluminum, aluminum alloys, Fiberglass, PVC pipes,Wood and so on. General-purpose operation of cutting /grinding.
